Product Overview
The CHIT-E and CHOT-E Series from COMPAQ International are extra high voltage (EHV) heat shrink termination kits designed for XLPE-insulated power cables operating at 66/72.5kV. Developed for reliable field performance, these kits are built with non-tracking insulation and stress control sleeve technology to ensure optimal electrical stress management and environmental sealing.
Suitable for both indoor switchgear and outdoor substation installations, these terminations are tested to international standards and manufactured in ISO-certified facilities. Backed by over 25 years of industry expertise, COMPAQ’s EHV solutions are deployed globally across utilities, industrial infrastructure, and renewable energy projects.
Prevents ingress and maintains long-term dielectric integrity in outdoor and underground applications.
Ensures even electrical field distribution at termination ends for safe EHV performance.
Protects against vibration, impact, and environmental stress during and after installation.
Suitable for installations with limited space or multi-phase deployment schedules.
Manufactured with full traceability and compliance with IEC, RoHS, and REACH directives.
| Parameter | Specification |
|---|---|
| Voltage Class | 66/72.5kV |
| Cable Insulation | XLPE |
| Conductor Material | Aluminium or Copper |
| Core Configuration | Single-core and three-core |
| Cable Armouring | SWA, AWA, or Unarmoured |
| Indoor Application | CHIT Series |
| Outdoor Application | CHOT Series |
| Insulation Material | Red non-tracking, UV-stabilized, heat shrinkable cross-linked polymer |
| Stress Control | High-performance CSCT tubing |
| Lug Compatibility | Mechanical and compression lugs |
| Installation Method | Heat shrink; requires standard torch or hot-air tool |
| Compliance Standards | IEC 60840 |
Applications
Selection Criteria
To identify the correct kit configuration, kindly confirm the following project details:
01
Voltage rating
02
Number of cores
03
Conductor size and type
04
Armouring details
05
Installation location (indoor or outdoor)
06
Connector type (mechanical or compression)
